New Products - December 2022 (5.5W Motors)

[DRow]

Individual 5.5W Motors for V5 & EXP are now available for purchase! They can be found here.

Note, these motors are still NOT legal for use in VRC / VAIC / VEX U (as of right now).

As always, international availability will vary.

[RoboCatz]

@DRow

NOT legal for use in VRC / VAIC / VEX (as of right now)

[VexTeamZ]

@DRow

Note, these motors are still NOT legal for use in VRC / VAIC / VEX (as of right now).

Does this mean you are on the GDC now?

[Mentor_355v]

Any indications these will be susceptible to the Rev10 diode problem described here:

V5 motors keep dying

I apologize for the radio silence on this thread. I just want to let you know that this topic is on the top of our priority list and we are working on it diligently to make sure it gets solved. Here are the updates I have: We have collected enough failed motors to know that the issue only happens on revision 10 of our motor PCBs. What we have determined is that something is causing a diode to fail on that revision. When that diode fails it brings the power rail down on the entire board and the…

[levipope]

@Mentor_355v

Any indications these will be susceptible to the Rev10 diode problem described here:

No, The 5.5w motor is a completely different design.

[turbodog]

To play devil’s advocate…

Why redesign a motor if the old one was working well? This takes time & money, so why spend them if not needed?

Were the internal mechanicals beefed up?

Are electronics more ESD resistant?

Has thermal mgmt been improved?

Etc…

[sazrocks]

Are these motors more resistant to static-related issues than the 11w V5 motors? For instance, do they have static protection diodes?

[sazrocks]

The product page for this motor is devoid of almost any details about the motor itself, and there is no kb article that I can find. More questions:

• What RPM does the motor spin at? The product page says “Note: This motor operates at a set RPM” without actually specifying what RPM that is.
• What is the TPR or resolution of the motor’s encoder?
• Is the threading on the mounts 8/32 as on the 11w motor?
• What is the stall torque of the motor?
• What is the torque/speed/power curve of the motor?
• As demonstrated with the 11w V5 smart motor, the metal mounting standoffs and mounting legs can be and are damaged quite often. Will there be replacement motor caps/standoffs for the 5.5w motor?
• At what temperature will performance begin to be limited?
• How does the current limiting system in VEXos react when a 5.5w motor is used? Is it the same as if it were a 11w motor?
• What is the current limit of this motor?
• Does the motor regulate its internal voltage similarly to the 11w motor?
• If so, what voltage does it regulate to?

[Max_Johnson03]

they’re cheaper for a different use and clientele

[jpearman]

I’ll answer some of these, some I would need to lookup details so will skip those.
This is not a new motor, it’s been shipping with EXP for several months.
The firmware is very similar to the 11W motor (same code base).

@sazrocks

What RPM does the motor spin at?

Nominal 200rpm, as far as V5 vexos is concerned it is similar to an 11W with green cartridge.

@sazrocks

What is the TPR or resolution of the motor’s encoder?

This is a little complicated. We had to make this motor play nicely with vexos, so as it is seen as a green cartridge motor which is 900 counts/rev. Internally it’s a little different.

@sazrocks

Is the threading on the mounts 8/32 as on the 11w motor?

yes

@sazrocks

What is the stall torque of the motor?

That I need to check, I want to say 0.5Nm, but I’ll verify that later.

@sazrocks

At what temperature will performance begin to be limited?

same as the 11W. 55C.

@sazrocks

How does the current limiting system in VEXos react when a 5.5w motor is used? Is it the same as if it were a 11w motor?

same as the 11W.

@sazrocks

What is the current limit of this motor?

2,5A

@sazrocks

Does the motor regulate its internal voltage similarly to the 11w motor?

This motor was primarily designed to work with EXP, so when used with V5 we run it at less than the maximum 12V we run the 11W motors at.

@sazrocks

If so, what voltage does it regulate to?

We limit the pwm to simulate about 7.2V, but that’s not an exact science.

[sazrocks]

More questions (oh how wonderful it would be to edit my post instead of making another):

• What are the dimensions of the motor?
• Is there a CAD model of the motor that can be published.

Ok that’s enough. To save everyone’s time, can all the information present on the 11w motor’s product page also be shown for the 5.5w motor on it’s page? That’s basically what these questions boil down to.

[jpearman]

again, this is not a new motor, see more info in this topic.

New Products - January 2021 (V5 Workcell)

The new V5 Smart Motor (5.5 W) motor is essentially a 393 Motor + IQ Smart Motor: [image] The new V5 Smart Motor (5.5 W) contains the motor from the 393 Motor, the same gearing and integrated encoder from an IQ Smart Motor, a new full metal gearbox output carrier (with a fourth planet instead of the three inside the IQ Smart Motor), and a new temperature sensor that will be adhered directly onto the motor itself (which is how we can get more usable mechanical power out of this motor compared t…

[VexTeamZ]

Some of these can be answered by this:

New Products - January 2021 (V5 Workcell)

The new V5 Smart Motor (5.5 W) motor is essentially a 393 Motor + IQ Smart Motor: [image] The new V5 Smart Motor (5.5 W) contains the motor from the 393 Motor, the same gearing and integrated encoder from an IQ Smart Motor, a new full metal gearbox output carrier (with a fourth planet instead of the three inside the IQ Smart Motor), and a new temperature sensor that will be adhered directly onto the motor itself (which is how we can get more usable mechanical power out of this motor compared t…

[kmmohn]

At one point it was mentioned that these are the old 393 Motors repackaged.

[sazrocks]

Great info, thanks for answering. Hopefully these can be put up on the product page soon, along with the info in Art’s post that you linked.

@jpearman

This is a little complicated. We had to make this motor play nicely with vexos, so as it is seen as a green cartridge motor which is 900 counts/rev. Internally it’s a little different.

Can you explain what you mean by this?

[jpearman]

We have to scale raw counts coming to the motor for spinTo position and out for the motor position. It’s something like a 15/8 factor, so 480 internal encoder counts becomes (480 * 15/8) 900 output counts. It just made vexos compatibility (along with all the sdk for VEXcode and PROS) a whole lot easier.

[jpearman]

There’s also more information here.

Understanding V5 Smart Motor (5.5W) Performance

Ignore the encoder spec, it’s technically not incorrect as that was/is the spec for the IQ motor, but implementation is as I explained above.

[sazrocks]

That’s a great article! Thanks for linking. Hopefully @DRow can fix that TPR issue. Maybe a link to that kb article can also be added from the V5 electronics kb? It would go here:

@jpearman

This motor was primarily designed to work with EXP, so when used with V5 we run it at less than the maximum 12V we run the 11W motors at.

What voltage does it end up getting capped at? I ask because then we’ll know what voltage range to use to control it when using voltage control.
